| Module Specifications | ||||||
| 1 | 产品型号:Model Number | PH1.25-64S | PH1.538-52S | PH1.86-43S | PH2-40S | PH2.5-32S |
| 2 | 模组尺寸:Module size | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm |
| 3 | 物理密度: Pixels Density | 640000点/㎡ | 422500点/㎡ | 288369点/㎡ | 250000点/㎡ | 160000点/㎡ |
| 4 | LED封装:Package mode | SMD1010 | SMD1212 | SMD1515 | SMD1515 | SMD1515/SMD2020 |
| 5 | 模组分别率:Pixel resolution | 256dots(W)*128dots(H) | 208dots(W)*104dots(H) | 172dots(W)*86dots(H) | 160dots(W)*80dots(H) | 128dots(W)*64dots(H) |
| 6 | 模组最大功耗:Max Power | 15-20W | 15-20W | 15-20W | 15-20W | 15-20W |
| 7 | 模组连接方式：Module connection mode | Flat cable | Flat cable | Flat cable | Flat cable | Ribbon cable connection |
| Cabinet Data | ||||||
| 1 | 箱体尺寸:Dimension | 680mm*480mm | 680mm*480mm | 680mm*480mm | 680mm*480mm | 680mm*480mm |
| 2 | 箱体分辨率:Pixel per cabinet | 512dots(W)*384dots(H) | 416dots(W)*312dots(H) | 344dots(W)*258dots(H) | 320dots(W)*240dots(H) | 256dots(W)*192dots(H) |
| 3 | 箱体模组数量:Number of modules per box | 6pcs | 6pcs | 6pcs | 6pcs | 6pcs |
| Screen Parameters | ||||||
| 1 | 扫描方式:Scan mode | 1/64scan | 1/52scan | 1/43scan | 1/40scan | 1/32scan |
| 2 | 白平衡亮度:Brightness of white balance | ≥400-800cd/㎡(adjustable) | ≥400-800cd/㎡(adjustable) | ≥400-800cd/㎡(adjustable) | ≥400-800cd/㎡(adjustable) | ≥400-800cd/㎡(adjustable) |
| 3 | 维护方式：Maintenance mode | Repair and maintenance at the front | Repair and maintenance at the front | Repair and maintenance at the front | Repair and maintenance at the front | Repair and maintenance at the front |
| 4 | 最佳视角:Best viewing angle | Horizontal 120° Vertical 120° | Horizontal 120° Vertical 120° | Horizontal 120° Vertical 120° | Horizontal 120° Vertical 120° | Horizontal 120° Vertical 120° |
| 5 | 环境温度:Temperature | storage:-25℃～+60℃ | storage:-25℃～+60℃ | storage:-25℃～+60℃ | storage:-25℃～+60℃ | storage:-25℃～+60℃ |
| 6 | working:-20℃～+50℃ | working:-20℃～+50℃ | working:-20℃～+50℃ | working:-20℃～+50℃ | working:-20℃～+50℃ | |
| 7 | 相对湿度:Relative humidity | 10%-75% | 10%-75% | 10%-75% | 10%-75% | 10%-75% |
| 8 | 工作电压:Working voltage | AC：110-220V±10%；50-60HZ | AC：110-220V±10%；50-60HZ | AC：110-220V±10%；50-60HZ | AC：110-220V±10%；50-60HZ | AC：110-220V±10%；50-60HZ |
| 9 | 平均功耗: Average Power consumption | <150-250W/㎡ | <150-250W/㎡ | <150-250W/㎡ | <150-250W/㎡ | <150-250W/㎡ |
| 10 | 最大功耗:Max.Power consumption | <400W/㎡ | <400W/㎡ | <400W/㎡ | <400W/㎡ | <400W/㎡ |
| 11 | 信号输入:Signal input | HDMI/DVI/SDI(Extensible interface) | HDMI/DVI/SDI(Extensible interface) | HDMI/DVI/SDI(Extensible interface) | HDMI/DVI/SDI(Extensible interface) | HDMI/DVI/SDI(Extensible interface) |
| 12 | 刷新频率:Refresh frequency | >1920-3840HZ | >1920-3840HZ | >1920-3840HZ | >1920-3840HZ | >1920-3840HZ |
| 13 | 灰度/颜色: Grey scale/colors | 14BIT | 14BIT | 14BIT | 14BIT | 14BIT |
| 14 | Red,Green and Blue 256 Grade/Each | Red,Green and Blue 256 Grade/Each | Red,Green and Blue 256 Grade/Each | Red,Green and Blue 256 Grade/Each | Red,Green and Blue 256 Grade/Each | |
| 15 | 安装模式:The installation mode | 1、Back bracket installation 2、Stick a wall installation |
1、Back bracket installation 2、Stick a wall installation |
1、Back bracket installation 2、Stick a wall installation |
1、Back bracket installation 2、Stick a wall installation |
1、Back bracket installation 2、Stick a wall installation |
